Shenzhen Yuante Technology Co., Ltd.
Regular price
$1,130.45 NZD
Regular price
$1,695.10 NZD
Sale price
$1,130.45 NZD
Taxes included.
Shipping calculated at checkout.
-
Alarm Mode : Sound+Light+Vibration
-
Target Gas : Carbon Monoxide, Flammable Gas, Hydrogen Sulfide, Oxygen
-
type : Multi-Gas Detector
-
Accuracy Class : Standard Accuracy
-
model number : YT-1200H-S
-
brand name : Safegas
-
place of origin : Guangdong, China
-
customized support : OEM
-
material : Plastic
-
warranty : 1 Year
-
Technical Specifications
|
Parameter
|
Value
|
|
Gas Detected
|
Specified according to application
|
|
Detection Principle
|
Diffusion
|
|
Sensor Type
|
Electrochemical (CO, H2S, O2); Catalytic Combustion (LEL)
|
|
Measuring Range
|
CO: 0–1000 ppmH2S: 0–100 ppmO2: 0–30%VOLLEL: 0–100%LEL
|
|
Resolution
|
CO: 1 ppm H2S: 1 ppm O2: 0.1%VOL LEL: 1%LEL
|
|
Precision
|
<1–5% F.S.
|
|
Display
|
Monochrome dot matrix 128×128 LCD graphic display
|
|
Backlight
|
Settable time; auto-on during alarm
|
|
Data Logging
|
Optional: 100,000 readings (10–3600 sec interval)
|
|
Event Logging
|
100 event records (standard, viewable on device)
|
|
Language
|
Chinese / English
|
|
Alarm Type
|
Sound, light, vibration
|
|
Battery
|
3.7V rechargeable lithium battery, 2500mAh
|
|
Working Time
|
14h continuous (4 gases); 200h (without LEL sensor)
|
|
Charger
|
Travel charger; charging time 4–6h
|
|
Explosion-Proof Grade
|
Ex ia IIC T4
|
|
Protection Grade
|
IP65
|
|
Working Temperature
|
10°C – 50°C
|
|
Working Humidity
|
15 – 95% RH
|
|
Housing Material
|
ABS + leather case
|
|
Dimensions (L × W × H)
|
131 × 83 × 35 mm
|
|
Weight
|
240g
|
