Shenzhen Yuante Technology Co., Ltd.
Regular price
$1,251.20 NZD
Regular price
$1,876.80 NZD
Sale price
$1,251.20 NZD
Taxes included.
Shipping calculated at checkout.
-
Alarm Mode : Sound+Light+Vibration
-
Target Gas : Sulfur Dioxide
-
type : Portable Gas Detector
-
Accuracy Class : Standard Accuracy
-
model number : MiniMeta
-
brand name : Safegas
-
place of origin : Guangdong, China
-
customized support : OEM
-
material : Plastic
-
warranty : 1 Year
-
Gas Detected : Sulfur Dioxide
-
Detection Principle : Electrochemical
-
Measuring Range : 0-100 ppm
-
Resolution : 0.01 ppm
-
Accuracy : ≤ ±2-5% FS
-
Response Time (T90) : 15-30 seconds (depending on specific sensor)
Key Technical Specifications
|
Parameter
|
Value
|
|
Target Gas
|
Sulfur Dioxide (SO2); compatible with O2, H2S, CO and hundreds of other gases
|
|
Sensing Principle
|
Imported Electrochemical Sensor
|
|
Measuring Range
|
0 – 100 ppm
|
|
Resolution
|
0.01 ppm
|
|
Accuracy
|
≤ ±2–5% FS
|
|
T90 Response Time
|
15–30 seconds
|
|
Display Content
|
Gas type, concentration, unit, battery, TWA/STEL/MAX/MIN
|
|
Alarm Configuration
|
95dB buzzer, dual red LEDs, vibration; adjustable high/low alarm, STEL, TWA, low battery, calibration & bump test reminders
|
|
Power Supply
|
3.6V replaceable non-rechargeable dry battery
|
|
Standby Cycle
|
2 years (no charging or regular calibration required)
|
|
Optional Functions
|
Event & data logging, automatic power-on self-test
|
|
Safety Standard
|
Ex ia IIC T4 Ga explosion-proof, IP68 waterproof & dustproof
|
|
Compliance Standards
|
GB 12358-2006, GB 3836 series, IEC 60079 series
|
|
Working Temp
|
-20°C ~ +55°C
|
|
Working Humidity
|
0–95% RH (non-condensing)
|
|
Air Pressure Range
|
86–106 kPa
|
|
Dimension
|
90 × 60 × 33 mm
|
|
Net Weight (with clip)
|
125 g
|
