Detector Personal De Gas H2S Portable Gas Detector
Detector Personal De Gas H2S Portable Gas Detector
Regular price
$403.65 NZD
Regular price
$604.90 NZD
Sale price
$403.65 NZD
Taxes included.
Shipping calculated at checkout.
- type : Detector Personal De Gas H2S
- model number : MiniMeta
- brand name : Safegas
- place of origin : Guangdong, China
- customized support : OEM
- warranty : 2 years
- Product : Detector Personal De Gas H2S
- Sensor type : Eletectrochemical
- Gas Detected : CO H2S O2 NH3 SO2, etc different gases
- Resolution : 1ppm, 0.1ppm, 0.1%VOL, etc
- Sampling method : Diffusion
- Response time : ≤ 30s (T90)
- Display : Gas name , concentration unit, measured value , electricity
- Alarm type : Low alarm, High alarm, STEL, TWA, low battery
- Explosion-proof grade : Ex ia II CT 4 Ga
- Protection class : IP68
Technical Specifications
|
Detected gas:
|
H2S, CO, O2, SO2, NH3, etc different single gases. According to customers' requirements.
|
|
Detection principle:
|
Electrochemical, according to gas, sensor and measure range.
|
|
Measure range:
|
Carbon Monoxide(CO): 0-500ppm/1000ppm/2000ppm, Hydrogen Sulfide(H2S): 0-100ppm/200ppm, Oxygen(O2): 0-25%VOL/30%VOL, according to customer's requirements.
|
|
Resolution:
|
Carbon Monoxide(CO): 1ppm, Hydrogen Sulfide(H2S): 0.01ppm, Oxygen(O2): 0.01%VOL, according to sensor and measure ranges.
|
|
Accuracy:
|
≤±3%F.S. (higher precision can be customized)
|
|
Response time:
|
≤30 seconds (T90)
|
|
Power Model:
|
3.6V dry battery (non-removable and rechargeable)
|
|
Display:
|
Gas name, concentration unit, measured value, electricity
|
|
Concentration unit:
|
ppm, mg/m3, %VOL, etc
|
|
Alarm mode:
|
Sound, light, vibration alarm, high and low alarm values can be set by yourself.
|
|
Explosion-proof grade:
|
IECEX ATEX(from TUV)
|
|
Protection Class:
|
IP68
|
|
Executive standards:
|
GB 12358-2006, GB 3836.1-2010, GB 3836.4-2010, JJF1421-2013, JJF1363-2019, JJF1364-2012, JJG 365-2008, IEC 60079-0-2017, IEC
60079-11-2 |
|
Working temperature:
|
-20℃～55℃
|
|
Working humidity:
|
0-95%RH (non-condensing
|
|
Working air pressure:
|
86~106kpa
|
|
Language:
|
English
|
|
Dimensions:
|
90*60*33mm (length*width*thickness)
|
|
Weight:
|
125g
|
